data transmission | |
Firewall-Durchsatz | 3,14 Gbit/s |
Firewall (IMIX) Durchsatz | 900 Gbit/s |
VPN (IMIX) Durchsatzleistung | 300 Mbit/s |
VPN (UDP 1518) Durchsatz | 1020 Gbit/s |
IPS/IDS Durchsatz | 525 Mbit/s |
Branch-Office-VPN | 10 |
Maximum Firewall Verbindungen pro Sekunde | 16000 |
Services | |
Simultaneous Connections | 1300000 |
Eigenschaft | Nachhaltigkeitskonformität |
Mean Time Between Failures (MTBF) | 1101388 h |
network | |
WLAN-Standards | Wi-Fi 6 (802.11ax) |
mesh standard | IEEE 802.11ax |
Number of VLANs | 10 |
safety | |
Supported security algorithms | SNMPv2, SNMPv3 |
logs | |
management logs | Syslog, SNMP v2/v3, WSM |
Supported network protocols | HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS and Explicit Proxy |
management functions | |
connections and interfaces | |
transmission technology | Kabelgebunden |
Number of 10G Ethernet (copper) ports | 5 |
Number of USB 2.0 ports | 2 |
Number of serial ports | 1 |
WAN port | Ethernet (RJ-45) |
energy | |
AC input voltage | 100-240 V |
input current | 2.5 A |
DC input voltage | 12 V |
Power consumption (standard operation) | 24 W |
Number of power supply units | 1 |
certificates | |
Konformitätsbescheinigungen | REACH, RoHS, WEEE |
certification | WEEE, RoHS, REACH, IPv6 Ready Gold |
sustainability | |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -25 - 75 °C |
Operating relative humidity | 5 - 90% |
humidity during storage | 5 - 90% |
operating height | 0 - 3000 m |
storage height | 0 - 4570 m |
weight and dimensions | |
broad | 203,2 mm |
depth | 215,9 mm |
height | 43,2 mm |
Weight | 880 g |
package weight | 1,86 kg |
scope of delivery | |
Included software | ###REMOVE### |
Other functions | |
Firewall Durchsatz | 3140 Mbit/s |
