WAN connection | |
Eigenschaft | Entfernbare Antennen |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max.) | 1300 Mbit/s |
WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
Number of VPN tunnels | 10 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
management functions | |
safety | BSMI, UL |
Supported security algorithms | SSID, SSL/TLS |
logs | |
Design | |
Product color | Grau, Rot |
LED indicators | Aktivität, LAN, Leistung, WAN, WLAN, WPS |
product type | Tragbarer Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
Antenna connector type | N-Typ |
Antenna gain level (max) | 3 dBi |
number of antennas | 3 |
features | |
heat dissipation | 61,38 BTU/h |
Mean Time Between Failures (MTBF) | 44000 h |
Electromagnetic compatibility | FCC Part 15 (Class B), IC, CE EMC (Class B), RCM, BSMI |
energy | |
energy source | Gleichstrom |
Power consumption (standard operation) | 18 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -30 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
weight and dimensions | |
broad | 216 mm |
depth | 143 mm |
height | 33 mm |
Weight | 1,14 kg |
package weight | 1,5 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
Other functions | |
Number of USB ports | 1 |
frequency band | 2.4 & 5 |
