Services | |
Maximum data transfer rate | 1200 Mbit/s |
Eigenschaft | Betriebsanleitung |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of Power over Ethernet (PoE) ports | 1 |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3at |
PowerLine-Standard | HomePlug AV2 |
Modulation | 8-QAM, 16-QAM, 64-QAM, 256-QAM, 4096-QAM, BPSK, OFDM, QPSK, ROBO |
Supported security algorithms | 128-bit AES |
chipset | Qualcomm QCA7500 + QCA8334 |
frequency range | 2 - 68 MHz |
energy | |
Power consumption (standard operation) | 32 W |
Power consumption (standby) | 3 W |
AC input voltage | 85-265 V |
Power over Ethernet (PoE) performance per port | 30 W |
Design | |
Product color | Weiß |
housing material | Kunststoff |
certification | CE |
system requirement | |
operating conditions | |
operating temperatur | 0 - 70 °C |
Storage temperature range | -10 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 95% |
weight and dimensions | |
broad | 65 mm |
depth | 30 mm |
height | 115 mm |
Weight | 300 g |
Technical details | |
sustainability certificates | RoHS |
Konformitätsbescheinigungen | RoHS |
scope of delivery | |
quantity per pack | 1 Stück(e) |
Supplied cables | LAN (RJ-45) |
