| WAN connection | |
| Eigenschaft | xDSL-Verbindung |
| Wireless LAN functions | |
| Top WLAN-Standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max.) | 300 Mbit/s |
| WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Modulation | 16-QAM, 64-QAM, BPSK, OFDM, QPSK |
| network | |
| Interface type Ethernet LAN | Schnelles Ethernet |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| wiring technology | 10/100Base-T(X) |
| mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| VPN support | IPSEC, PPTP, L2TP |
| DSL features | |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 4 |
| management functions | |
| safety | |
| Supported security algorithms | 128-bit WEP, 64-bit WEP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK, WPA2-TKIP, WPS |
| authentication method | PAP, CHAP |
| logs | |
| management logs | DNS, SNMP, |
| Data Link Protocols | PPP |
| Supported network protocols | IGMP, DHCP |
| Design | |
| Product color | Weiß |
| Antenna | |
| The Antenna Design | Extern |
| number of antennas | 2 |
| energy | |
| Power consumption (standard operation) | 5 W |
| operating conditions | |
| operating temperatur | 0 - 50 °C |
| Storage temperature range | 10 - 90 °C |
| Operating relative humidity | -20 - 65% |
| humidity during storage | 30 - 95% |
| weight and dimensions | |
| broad | 95 mm |
| depth | 110 mm |
| height | 27 mm |
| Weight | 465 g |
| Other functions | |
| Data transfer speed WiFi | 1,2,5.5,6,9,12,18,24,36,48,300 Mbit/s |
