WAN connection | |
Eigenschaft | Schnellinstallationsanleitung |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max.) | 866 Mbit/s |
WLAN-Standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (first band) | 866 Mbit/s |
WLAN data transfer rate (second band) | 400 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
mobile network | |
Cellular Network Generation | 5G |
3G standards | HSPA+, UMTS |
4G LTE-Kategorie | 16 |
supported 4G bandwidths | 1500,3500,3700 MHz |
SIM card type | MiniSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
RJ-11 ports quantity | 1 |
management functions | |
safety | |
Supported security algorithms | WPA2, WPA3, WPS |
logs | |
Design | |
Product color | Schwarz, Rot, Weiß |
product type | Tabletop-Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
Antenna connector type | SMA |
number of antennas | 2 |
energy | |
energy source | Gleichstrom |
Power consumption (standard operation) | 6 W |
weight and dimensions | |
broad | 208 mm |
depth | 150 mm |
height | 37 mm |
