WAN connection | |
Eigenschaft | Power over Ethernet (PoE) |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN data transfer rate (max.) | 600 Mbit/s |
WLAN-Standards | 802.11a, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
mesh standard | IEEE 802.3at |
mobile network | |
Cellular Network Generation | 5G |
3G standards | HSPA+, UMTS |
4G-Standards | LTE-A |
4G LTE-Kategorie | 19 |
5G bands supported | 700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3800,1400 MHz |
supported 4G bandwidths | 1500,3500,3700 MHz |
SIM card type | NanoSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
management functions | |
Number of data streams | 2x2 |
safety | |
Supported security algorithms | IPSec, WPA2, WPA3 |
logs | |
Design | |
Product color | Weiß |
International degree of protection (IP code) | IP54 |
product type | Tabletop-Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Intern |
antenna type | 4x4 |
features | |
Number of devices that can be connected simultaneously (max) | 50 |
energy | |
energy source | PoE |
Power consumption (standard operation) | 6,8 W |
operating conditions | |
operating temperatur | -10 - 40 °C |
weight and dimensions | |
broad | 111 mm |
depth | 163 mm |
height | 31 mm |
logistic data | |
Garantiezeit | 5 Jahr(e) |
Other functions | |
Uplink data rate | 900 Mbit/s |
Downstream data rate | 1300 Mbit/s |
