WAN connection | |
Eigenschaft | Eingebauter Prozessor |
WAN connection type | RJ-45 |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN data transfer rate (max.) | 2976 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
WLAN data transfer rate (first band) | 574 Mbit/s |
WLAN data transfer rate (second band) | 2402 Mbit/s |
Modulation | 1024-QAM, OFDMA |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
VPN-Server | WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
management functions | |
Number of data streams | 2x2 |
safety | |
Supported security algorithms | WPA, WPA2, WPA3 |
logs | |
Design | |
Product color | Weiß |
LED indicators | LAN, System, WAN, WLAN, WPS |
product type | Desktop-/Pol-Router |
certificates | |
certification | FCC, CE |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
Antenna gain level (max) | 5,3 dBi |
number of antennas | 4 |
features | |
processor architecture | ARM Cortex-A53 |
processor clock speed | 1300 MHz |
number of CPU cores | 2 |
storage capacity | 256 MB |
Internal storage type | DDR3 |
Flash memory | 128 MB |
Number of devices that can be connected simultaneously (max) | 200 |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
output voltage | 12 V |
output current | 1 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 173 mm |
depth | 123,8 mm |
height | 33 mm |
Weight | 329,4 g |
package weight | 725 g |
packaging type | Box |
Number of products included | 1 Stück(e) |
