Housing material | Plastic |
Product Type | Tabletop router |
Product colour | Grey |
LED indicators | DSL, LAN, Power, VPN |
Output voltage | 12 V |
Output current | 2 A |
AC input voltage | 230 V |
Power source type | AC |
NAT functionality | NAT-T |
URL filtering | Yes |
Guest access | Yes |
System event log | Yes |
DoS attack prevention | Yes |
Firewall | Yes |
Authentication method | PAP, CHAP, MS-CHAP, MS-CHAPv2 |
IP address filtering | Yes |
Access Control List (ACL) | Yes |
Firewall security | SIF |
DMZ support | Yes |
Filtering | Yes |
Security algorithms | SHA-1 |
MAC address filtering | Yes |
Network address translation (NAT) | Yes |
Operating temperature (T-T) | 0 - 35 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web-based setup wizard | Yes |
Reset button | Yes |
Web-based management | Yes |
DESPITE | Yes |
Quality of Service (QoS) support | Yes |
Number of data streams | 2x2 |
Height | 45 mm |
Depth | 140 mm |
Weight | 500 g |
Width | 210 mm |
VPN support | IPSec, PPTP (MPPE), L2TPv2 |
VPN tunnels quantity | 5 |
Static route | Yes |
Multicast support | Yes |
Ethernet LAN | Yes |
Supports ISDN connection | Yes |
Ethernet LAN interface type | Gigabit Ethernet |
Dynamic DNS (DDNS) | Yes |
Port forwarding | Yes |
Cabling technology | 10/100/1000Base-T(X) |
Load balancing system | Yes |
Ethernet LAN data rates | 1000 Mbit/s |
Policy-based routing | Yes |
Networking standards | IEEE 802.11u |
Package depth | 288 mm |
Package height | 94 mm |
PACKAGE WEIGHT | 1.64 kg |
Package width | 385 mm |
Manual | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max) | 1733 Mbit/s |
WLAN data transfer rate (first band) | 300 Mbit/s |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (second band) | 867 Mbit/s |
Routing protocols | LISP |
Supported network protocols | DNS, HTTP, HTTPS, ICMP, NTP/SNTP, NetBIOS, PPPoE (server), RADIUS, RADSEC (secure RADIUS), RTP, SNMPv1,v2c,v3, TFTP, TACACS+ |
VoIP Protocols | SIP ALG |
DHCP Server | Yes |
Management protocols | SNMPv1,v2c,v3, SNMP-TRAPS |
DHCP client | Yes |
Memory card slot(s) | No |
USB Port | Yes |
RJ-11 ports quantity | 2 |
DC-in jack | Yes |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 4 |
Antenna design | Internal |
Ethernet WAN | Yes |
DSL WAN | Yes |
Country of origin | Germany |
Harmonized System (HS) code | 85176990 |
Customs product code (TARIC) | 85176200 |
VDSL2 | Yes |
ADSL2+ | Yes |
ADSL2 | Yes |
VDSL | Yes |
