WAN connection | |
Eigenschaft | Mac-Kompatibilität |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 4 (802.11n) |
WLAN data transfer rate (max.) | 1733 Mbit/s |
WLAN data transfer rate (first band) | 800 Mbit/s |
WLAN data transfer rate (second band) | 1733 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
VPN support | PPTP, OpenVPNTM, L2TP IPSec |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 5 |
Number of USB 2.0 ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
Compatible memory cards | SD, SDHC, SDXC |
management functions | |
safety | |
Supported security algorithms | WEP, WPA, WPA2, WPS |
Firewall | IPv4, IPv6 |
logs | |
Supported network protocols | IPv4, IPv6, FTP, FTP SSL / TLS, SFTP |
Design | |
Product color | Schwarz |
product type | Tabletop-Router |
certificates | |
certification | RoHS, CE, FCC, NCC, RCM |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
Antenna gain level (max) | 4,5 dBi |
number of antennas | 4 |
features | |
processor clock speed | 1700 MHz |
number of CPU cores | 2 |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
operating conditions | |
operating temperatur | 5 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 5 - 95% |
operating height | 0 - 5000 m |
system requirement | |
Supports Mac operating systems | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
weight and dimensions | |
broad | 280 mm |
depth | 169 mm |
height | 77 mm |
Weight | 700 g |
logistic data | |
Goods tariff number (HS) | 85176990 |
