WAN connection | |
Eigenschaft | Power over Ethernet (PoE) |
network | |
mesh standard | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
Ethernet interfaces type | Gigabit Ethernet |
wiring technology | 10/100Base-T(X) |
mobile network | |
Cellular Network Generation | 4G |
4G-Standards | LTE |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
Fast Ethernet (copper) ports | 2 |
Number of Power over Ethernet (PoE) ports | 2 |
logs | |
management logs | FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS |
VoIP Protocol | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
safety | |
Supported security algorithms | HTTPS |
scope of delivery | |
features | |
processor clock speed | 580 MHz |
Flash memory | 16 MB |
storage capacity | 128 MB |
Installed operating system | RutOS |
certification | CE, UKCA, EAC, UCRF, RCM |
Design | |
Product color | Weiß |
housing material | Kunststoff |
LED indicators | Status |
Antenna | |
antenna type | Intern |
number of antennas | 2 |
energy | |
Power consumption (standard operation) | 2,5 W |
Power consumption (max.) | 6 W |
energy source | Gleichstrom, PoE |
operating conditions | |
operating temperatur | -40 - 75 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 100 mm |
depth | 235 mm |
height | 49,3 mm |
Weight | 855 g |
Other functions | |
input voltage | 42.5 - 57 V |
