Design | |
device type | Router für Mobilfunknetz |
Product color | Schwarz |
housing material | Aluminium, Kunststoff |
Assembly | DIN-Schiene |
market positioning | Industriell |
Eigenschaft | Web-basiertes Management |
Ethernet LAN characteristics | |
Interface type Ethernet LAN | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
mesh standard | IEEE 802.3, IEEE 802.3u |
Wireless LAN functions | |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
mobile network | |
data network | 2G, 3G, 4G |
4G-Standards | LTE |
2G bands are supported | 900,1800 MHz |
supported 3G bandwidths | 850,900,2100 MHz |
supported 4G bandwidths | 2300,2500,2600 MHz |
Number of SIM cards | 1 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | HTTPS, SSH, SSL/TLS, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
Services | |
processor clock speed | 0,58 GHz |
RAM capacity | 0,128 GB |
management functions | |
Antenna | |
antenna type | Extern |
Antenna connector type | SMA |
number of antennas | 3 |
energy | |
energy source | Gleichstrom |
output voltage | 9 - 30 V |
operating conditions | |
operating temperatur | -40 - 75 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 83 mm |
depth | 74 mm |
height | 25 mm |
Weight | 125 g |
logistic data | |
Goods tariff number (HS) | 85176990 |
