Design | |
device type | Router für Mobilfunknetz |
Product color | Schwarz |
housing material | Aluminium |
Assembly | DIN-Schiene |
Eigenschaft | Entfernbare Antennen |
LED indicators | 3G, Daten, Netzwerk, Leistung, System |
Ethernet LAN characteristics | |
Interface type Ethernet LAN | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
mesh standard | IEEE 802.11e, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u |
Wireless LAN functions | |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
WiFi frequency | 2,4 GHz |
mobile network | |
data network | 2G, 3G, 4G, LTE |
4G-Standards | LTE |
Number of SIM cards | 2 |
SIM card type | MiniSIM |
Data transfer rate (LTE) (download) | 150 Mbit/s |
Data transfer rate (LTE) (upload) | 50 Mbit/s |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
USB-Port-Typ | USB Typ-A |
Number of USB 2.0 ports | 1 |
serial interface | |
Serial interface | RS-232, RS-485 |
safety | |
Supported security algorithms | AES-CCMP, FTPES, TKIP, WEP, WPA-PSK, WPA2-Enterprise-PEAP, WPA3-EAP, WPA3-SAE |
VPN support | OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc |
GPS Services | |
Services | |
processor manufacturer | Mediatek |
processor clock speed | 0,58 GHz |
RAM capacity | 0,128 GB |
RAM type | DDR2 |
Internal storage capacity | 0,016 GB |
Installed operating system | RutOS |
management functions | |
Antenna | |
antenna type | Extern |
Antenna connector type | SMA/RP-SMA |
number of antennas | 5 |
energy | |
energy source | Gleichstrom |
operating conditions | |
operating temperatur | -40 - 75 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 109,5 mm |
depth | 100 mm |
height | 50 mm |
Weight | 295 g |
