Processor model | MIPS 1004Kc |
Operating system installed | RutOS |
Processor frequency | 880 MHz |
STORAGE MEDIA | Flash |
Internal memory type | DDR3 |
INTERNAL MEMORY | 256 MB |
Built-in processor | Yes |
Flash Memory | 256 MB |
Processor manufacturer | MediaTek |
LED indicators | Yes |
Product colour | Black |
Power consumption (max) | 12.3 W |
Power consumption (typical) | 3.9 W |
Power source type | DC |
Power plug type | Type E |
MAC address filtering | Yes |
Security algorithms | AES |
IP address filtering | Yes |
Network address translation (NAT) | Yes |
Firewall security | Port forward, traffic rules, custom rules |
Firewall | Yes |
ARP attack prevention | Yes |
ICMP attack prevention | Yes |
Operating temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 10 - 90% |
Web-based management | Yes |
Wake-on-LAN ready | Yes |
Quality of Service (QoS) support | Yes |
Firmware upgradeable | Yes |
Reset button | Yes |
Universal Plug and Play (UPnP) | Yes |
Depth | 95.1 mm |
Height | 44.2 mm |
Weight | 460 g |
Width | 115 mm |
Networking standards | IEEE 802.3u |
Auto MDI/MDI-X | Yes |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN data rates | 100 |
Cabling technology | 10/100/1000Base-T(X) |
Traffic control | Yes |
VLAN support | Yes |
Port forwarding | Yes |
Static route | Yes |
DHCP client | Yes |
DHCP Server | Yes |
Routing protocols | EIGRP |
DMZ support | Yes |
VoIP Protocols | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
Ethernet LAN (RJ-45) ports | 4 |
USB version | 2.0 |
WAN ports quantity | 1 |
WAN/Ethernet LAN ports quantity | 3 |
Gigabit Ethernet (copper) ports quantity | 4 |
USB ports quantity | 1 |
Ethernet WAN | Yes |
SFP WAN | No |
SIM card slot | Yes |
DSL WAN | No |
3G/4G USB modem compatibility | No |
Warnings | Make sure the unit is stably mounted and ventilated. |
