WAN connection | |
Eigenschaft | LED-Anzeigen |
network | |
mesh standard | IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
mobile network | |
Cellular Network Generation | 4G |
4G-Standards | LTE |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
Number of USB ports | 1 |
USB-Version | 2.0 |
logs | |
Router protocol | OSPFv2, BGP, RIP-1, RIP-2 |
VoIP Protocol | H.323, SIP-alg |
Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, UDP, NTP, DNS, HTTP, FTP, SMTP, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP |
safety | |
Supported security algorithms | SNMP, SNMPv3, SSH |
features | |
processor clock speed | 717 MHz |
number of CPU cores | 4 |
Flash memory | 256 MB |
storage capacity | 256 MB |
Internal storage type | DDR2 |
Installed operating system | RutOS |
Design | |
Product color | Aluminium |
housing material | Aluminium |
Antenna | |
Antenna connector type | SMA |
operating conditions | |
operating temperatur | -40 - 75 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 95 mm |
depth | 44 mm |
height | 115 mm |
Weight | 456 g |
