Certification | CE/RED, EAC, RoHS, WEEE
Draft ETSI EN 301 489-1 V2.2.0, Draft EN 301 489-19 V2.1.0, Draft ETSI EN 301 489-52 V1.1.0
EN 61000-4-2:2009
EN 300 511 V12.5.1, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2
EN 61000-4-3:2006 + A1:2008 + A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2014
EN 61000-4-6:2014
EN 61000-4-11:2004 |
Safety | IEC 62368-1:2014, EN 50385:2017, EN 62232:2017 |
LED indicators | Power |
Product colour | Grey |
VLAN support | Yes |
Network address translation (NAT) | Yes |
Operating temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 10 - 90% |
Reset button | Yes |
Quality of Service (QoS) support | Yes |
Height | 74 mm |
Weight | 165 g |
Depth | 25 mm |
Width | 83 mm |
Forwarding rate | 150 Mpps |
Ethernet LAN data rates | 10 |
Networking standards | IEEE 802.3 |
DMZ support | Yes |
Management protocols | SNMP |
SIM card slot | Yes |
Serial interface type | RS-232/485 |
console port | RS-232 |
RS-232 ports | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Harmonized System (HS) code | 85176990 |
