WAN connection | |
Eigenschaft | Mac-Kompatibilität |
WAN connection type | RJ-45 |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max.) | 867 Mbit/s |
WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
WLAN data transfer rate (first band) | 300 Mbit/s |
WLAN data transfer rate (second band) | 867 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Number of guest networks (2.4 GHz) | 1 |
Number of guest networks (5 GHz) | 1 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
management functions | |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
Firewall | DoS, SPI Firewall, IP and MAC Address Binding |
logs | |
Router protocol | IP |
Supported network protocols | IPv4, IPv6 |
Design | |
Product color | Schwarz |
LED indicators | LAN, Leistung, Status, WLAN, WPS |
product type | Tabletop-Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
number of antennas | 5 |
transmit power | CE EIRP: <20dBm(2.4GHz); <23dBm(5GHz) |
energy | |
energy source | Gleichstrom |
output voltage | 12 V |
output current | 1 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
system requirement | |
Supports Windows operating systems | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Supports Mac operating systems | macOS |
weight and dimensions | |
broad | 230 mm |
depth | 144 mm |
height | 35 mm |
Number of products included | 1 Stück(e) |
