WAN connection | |
Eigenschaft | Rack-Einbau |
network | |
mesh standard | IEEE 802.1D, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Ethernet interfaces type | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 5 |
Number of installed SFP modules | 1 |
Number of USB ports | 1 |
logs | |
safety | |
Supported security algorithms | 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SHA-2, SHA-384, SHA-512 |
Number of VPN tunnels | 50 |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
scope of delivery | |
Supplied cables | AC |
features | |
Flash memory | 128 MB |
storage capacity | 512 MB |
Internal storage type | DDR4 |
Supports Windows operating systems | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Design | |
Product color | Schwarz |
energy | |
Power consumption (max.) | 7,5 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 294 mm |
depth | 140 mm |
height | 44 mm |
