| Compliance certificates | RoHS |
| Certification | CE, FCC, RoHS |
| Mac operating systems supported | MacOS |
| Windows operating systems supported | Windows 2000 |
| Internal memory type | DRAM |
| Flash Memory | 16 MB |
| Linux operating systems supported | Yes |
| INTERNAL MEMORY | 256 MB |
| Product colour | Black |
| LED indicators | System |
| Rack capacity | 1U |
| Rack mounting | Yes |
| Embedded DRAM (eDRAM) memory | 128 MB |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 120 - 240 V |
| Power consumption (typical) | 7.94 W |
| Power source type | AC |
| NAT functionality | • One-to-One NAT
• Multi-Net NAT
• Virtual Server
• Port Triggering
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
| VPN support | • 20 IPsec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
• PPTP VPN Server
• 10 PPTP VPN Clients
• 16 Tunnels
• PPTP with MPPE Encryption
• L2TP VPN Server
• 10 L2TP VPN Clients
• 16 Tunnels
• L2TP over IPSec
• OpenVPN Server
• 10 OpenVPN Clients
• 16 OpenVPN Tunnels |
| Network address translation (NAT) | Yes |
| Security algorithms | 192-bit AES |
| VPN tunnels quantity | 20 |
| Authentication method | SHA-1, MD5 |
| URL filtering | Yes |
| System event log | Yes |
| Firewall | Yes |
| ARP attack prevention | Yes |
| DoS attack prevention | Yes |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Web-based management | Yes |
| Reset button | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Height | 25 mm |
| Width | 158 mm |
| Depth | 101 mm |
| Networking standards | IEEE 802.3u |
| Ethernet LAN data rates | 10 |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Policy-based routing | Yes |
| Concurrent connections | 150000 |
| Traffic control | Yes |
| VLAN support | Yes |
| Manual | Yes |
| Quick installation guide | Yes |
| Package depth | 254 mm |
| Package height | 60 mm |
| Quick start guide | Yes |
| PACKAGE WEIGHT | 650 g |
| Package width | 190 mm |
| CABLES INCLUDED | AC |
| Supported protocols | IPsec/PPTP/L2TP |
| DHCP client | Yes |
| Supported network protocols | TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP |
| DMZ support | Yes |
| DHCP Server | Yes |
| Routing protocols | RIP-1 |
| Management protocols | Telnet |
| Ethernet LAN (RJ-45) ports | 5 |
| USB ports quantity | 1 |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
