WAN connection | |
Eigenschaft | DHCP-Server |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN data transfer rate (max.) | 2402 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
mobile network | |
Cellular Network Generation | 4G |
3G standards | HSDPA, HSUPA, WCDMA |
4G-Standards | LTE-TDD & LTE-FDD |
supported 4G bandwidths | 800,850,900,1800,2100,2300,2500,2600 MHz |
SIM card type | NanoSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 5 |
management functions | |
safety | |
NAT functionality | • One-to-One NAT• Multi-Net NAT• Virtual Server• Port Triggering†• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnP |
logs | |
Design | |
Product color | Schwarz |
LED indicators | LAN, LTE, Status, System, WAN |
product type | Desktop-/Pol-Router |
Antenna | |
The Antenna Design | Extern |
number of antennas | 5 |
features | |
storage capacity | 512 MB |
Internal storage type | DDR4 |
Flash memory | 128 MB |
energy | |
energy source | AC |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 226 mm |
depth | 131 mm |
height | 35 mm |
