WAN connection | |
Eigenschaft | Schnellinstallationsanleitung |
WAN connection type | RJ-45 |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max.) | 2033 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (first band) | 300 Mbit/s |
WLAN data transfer rate (second band) | 1733 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
VPN support | OpenVPN, PPTP VPN, IPSec VPN |
DSL features | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 3 |
RJ-11 ports quantity | 3 |
management functions | |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2 |
logs | |
Design | |
Product color | Schwarz |
product type | Tabletop-Router |
certificates | |
certification | CE, RoHS |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45), Telefon (RJ-11) |
Antenna | |
The Antenna Design | Intern & extern |
number of antennas | 4 |
energy | |
energy source | AC |
output voltage | 12 V |
output current | 2 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 216 mm |
depth | 163,7 mm |
height | 36,8 mm |
package weight | 1,22 kg |
