| WAN connection | |
| Eigenschaft | Mac-Kompatibilität |
| Wireless LAN functions | |
| WiFi band | Dual-Band (2,4 GHz/5 GHz) |
| Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max.) | 867 Mbit/s |
| WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| network | |
| Interface type Ethernet LAN | Schnelles Ethernet |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h |
| Äquivalente isotrope Strahlungsleistung (EIRP) (bei IEEE 802.11b) | 20 dBmW |
| Äquivalente isotrope Strahlungsleistung (EIRP) (bei IEEE 802.11g) | 20 dBmW |
| Äquivalente isotrope Strahlungsleistung (EIRP) (bei IEEE 802.11n) | 20 dBmW |
| DSL features | |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 4 |
| RJ-11 ports quantity | 1 |
| management functions | |
| safety | |
| Supported security algorithms | IPSec, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| logs | |
| Design | |
| Product color | Schwarz |
| product type | Tabletop-Router |
| certificates | |
| certification | CE, RoHS, RCM |
| scope of delivery | |
| Supplied cables | LAN (RJ-45), Telefon (RJ-11) |
| Antenna | |
| The Antenna Design | Extern |
| number of antennas | 4 |
| energy | |
| output voltage | 12 V |
| output current | 1 A |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| system requirement | |
| weight and dimensions | |
| broad | 385 mm |
| depth | 76 mm |
| height | 290 mm |
| package weight | 840 g |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
