| WAN connection | |
| Eigenschaft | Unterstützt Mac-Betriebssysteme |
| WAN connection type | RJ-45 |
| Wireless LAN functions | |
| WiFi band | Einzelband (2,4GHz) |
| Top WLAN-Standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max.) | 300 Mbit/s |
| WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| network | |
| Interface type Ethernet LAN | Schnelles Ethernet |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| wiring technology | 10/100Base-T(X) |
| mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Äquivalente isotrope Strahlungsleistung (EIRP) (bei IEEE 802.11n) | 20 dBmW |
| Recipient Sensitivity | 11g 54M: -74dBm11n HT20: -71dBm11n HT40: -67dBm |
| mobile network | |
| Cellular Network Generation | 4G |
| 3G standards | HSPA, UMTS |
| 4G-Standards | LTE-TDD & LTE-FDD |
| supported 4G bandwidths | 800,900,1800,1900,2100,2300,2500,2600 MHz |
| supported 3G bandwidths | 850,900,2100 MHz |
| SIM card type | MicroSIM |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 2 |
| management functions | |
| safety | |
| Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| logs | |
| Supported network protocols | IPv4, IPv6 |
| Design | |
| Product color | Schwarz |
| product type | Tabletop-Router |
| certificates | |
| certification | CE, RoHS |
| scope of delivery | |
| Supplied cables | LAN (RJ-45) |
| Antenna | |
| The Antenna Design | Extern |
| Antenna connector type | N-Typ |
| number of antennas | 2 |
| features | |
| energy | |
| energy source | Gleichstrom |
| output voltage | 9 V |
| output current | 0,85 A |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| system requirement | |
| Supported browser | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Supports Windows operating systems | Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| weight and dimensions | |
| broad | 154 mm |
| depth | 114 mm |
| height | 36 mm |
| Weight | 150 g |
| package weight | 450 g |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
