Design | |
device type | Router für Mobilfunknetz |
Product color | Schwarz |
housing material | Aluminium, Polycarbonat (PC) |
Assembly | DIN-Schienen-/Wandmontage |
Eigenschaft | Benutzerhandbuch |
LED indicators | Status |
Ethernet LAN characteristics | |
Interface type Ethernet LAN | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
Wireless LAN functions | |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Data transfer speed WiFi | 1,2,5.5,6,9,11,12,18,24,36,48,54,150,6.5 Mbit/s |
WiFi frequency | 2,4 GHz |
mobile network | |
data network | 4G |
4G-Standards | LTE |
Number of SIM cards | 1 |
SIM card type | NanoSIM |
Data transfer rate (LTE) (download) | 150 Mbit/s |
Data transfer rate (LTE) (upload) | 50 Mbit/s |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
USB-Port-Typ | USB Typ-C |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), Industry Canada (IC), PTCRB, GCF |
Services | |
antenna type | Extern |
Antenna connector type | SMA/RP-SMA |
number of antennas | 3 |
energy | |
energy source | Gleichstrom, USB |
Power consumption (standard operation) | 5,7 W |
input voltage | 5 - 30 V |
operating conditions | |
operating temperatur | -30 - 70 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 82 mm |
depth | 26 mm |
height | 193,5 mm |
Weight | 200 g |
