Compliance certificates | Federal Communications Commission (FCC) |
Antenna direction type | Omni-directional |
Internal | No |
Operating modes | Infrastructure mode |
Transmitting power (CE) | 20 dBm |
Antenna design | Internal |
Transmitting power (FCC) | 20 dBm |
Antenna | Yes |
Component for | PC/Laptop |
Product colour | Black |
USB powered | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Width | 15 mm |
Height | 18.6 mm |
Depth | 7.1 mm |
Networking standards | IEEE 802.1x |
Security algorithms | WPA-PSK |
Maximum data transfer rate | 433 Mbit/s |
WLAN data transfer rates supported | 433 Mbit/s |
Wi-Fi standards | 802.11g |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Wi-Fi | Yes |
Frequency range | 2.4 - 5 GHz |
Modulation | 16-QAM |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Windows operating systems supported | Windows 8 |
Mac operating systems supported | MacOS |
PACKAGE WEIGHT | 90 g |
Package height | 30 mm |
Package width | 138 mm |
Package depth | 128 mm |
Resource CD | Yes |
Quick installation guide | Yes |
Connectivity Technology | Wired |
Host Interface | USB |
Interface | WLAN |
USB version | 2.0 |
Harmonized System (HS) code | 85176990 |
Sustainability compliance | Yes |
