| connections and interfaces | |
| transmission technology | Kabellos |
| host interface | USB |
| interface | WLAN |
| USB-Version | 2.0 |
| network | |
| Maximum data transfer rate | 600 Mbit/s |
| mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac |
| Eigenschaft | Schnellinstallationsanleitung |
| WiFi band | Dual-Band (2,4 GHz/5 GHz) |
| frequency range | 2,4 - 5 GHz |
| Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
| WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Data transfer speed WiFi | 11,54,150,433,600 Mbit/s |
| Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
| Supported security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPS |
| Design | |
| component for | PC/Laptop |
| Product color | Schwarz |
| The Antenna Design | Intern |
| Antennenrichtungsart | Mit kugelförmiger Richtcharakteristik |
| Transmission power (CE) | 20 dbm |
| Transmission power (FCC) | 20 dbm |
| LED indicators | Status |
| Betriebsmodi | Infrastrukturmodus |
| system requirement | |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| sustainability | |
| weight and dimensions | |
| broad | 41 mm |
| depth | 19,5 mm |
| height | 8,7 mm |
| package weight | 90 g |
| scope of delivery | |
| Technical details | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
