LED indicators | Status |
Product colour | Black |
Antenna | Yes |
Operating modes | Infrastructure mode |
Antenna design | Internal |
Transmitting power (FCC) | 23 dBm |
Transmitting power (CE) | 23 dBm |
Antenna direction type | Omni-directional |
Component for | PC/Laptop |
Internal | No |
USB powered | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Height | 10.3 mm |
Depth | 19.7 mm |
Width | 40.5 mm |
WLAN data transfer rates supported | 400 |
Networking standards | IEEE 802.11a |
Security algorithms | WPA2-PSK |
Modulation | 256-QAM |
Maximum data transfer rate | 867 Mbit/s |
Frequency range | 2.4 - 5 GHz |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
MU-MiMO | Yes |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Wi-Fi | Yes |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Windows operating systems supported | Windows 10 Pro x64 |
Mac operating systems supported | Mac OS X 10.11 El Capitan |
Package depth | 128 mm |
PACKAGE WEIGHT | 90 g |
Package height | 30 mm |
Package width | 138 mm |
Resource CD | Yes |
Quick installation guide | Yes |
Connectivity Technology | Wired |
Host Interface | USB |
USB ports quantity | 1 |
Interface | WLAN |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
Harmonized System (HS) code | 85176990 |
Sustainability certificates | Federal Communications Commission (FCC) |
Sustainability compliance | Yes |
