connections and interfaces | |
transmission technology | Kabellos |
host interface | PCI Express |
interface | WLAN |
PCI-Karten-Formfaktor | Halbe Höhe (Niedriges Profil) |
network | |
Maximum data transfer rate | 867 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Eigenschaft | Störungsfrei |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Data transfer speed WiFi | 11,54,300,867 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
Supported security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK |
bandwidth (first) | 2,4 GHz |
bandwidth (second) | 5 GHz |
Design | |
component for | PC |
Product color | Schwarz, Grün |
The Antenna Design | Extern |
Transmission power (CE) | 23 dbm |
Transmission power (FCC) | 24 dbm |
Betriebsmodi | Infrastrukturmodus |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
sustainability | |
weight and dimensions | |
broad | 120,8 mm |
depth | 115,2 mm |
height | 21,5 mm |
Quantity | 1 |
packaging type | Box |
package weight | 300 g |
scope of delivery | |
Technical details | |
Konformitätsbescheinigungen | RoHS, Eidgenössische Kommunikationskommission (FCC), CE |
logistic data | |
Goods tariff number (HS) | 85176990 |
Other functions | |
number of antennas | 2 |
transmit power range | 59,5 - 92 dBmW |
