connections and interfaces | |
transmission technology | Kabellos |
host interface | USB |
interface | WLAN |
USB-Version | 3.2 Gen 1 (3.1 Gen 1) |
network | |
Maximum data transfer rate | 867 Mbit/s |
Eigenschaft | Schnellinstallationsanleitung |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
frequency range | 2,4 - 5 GHz |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Data transfer speed WiFi | 11,54,300,400,867 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
bandwidth (first) | 2,4 GHz |
bandwidth (second) | 5 GHz |
Design | |
component for | PC/Laptop |
Product color | Schwarz |
The Antenna Design | Extern |
Antennenrichtungsart | Mit kugelförmiger Richtcharakteristik |
LED indicators | Leistung |
certification | CE, FCC |
system requirement | |
Supports Windows operating systems | Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64, Windows 8.1, Windows 8.1 x64, Windows XP |
Supports Mac operating systems | Mac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 92,4 mm |
depth | 30,4 mm |
height | 13,9 mm |
scope of delivery | |
Technical details | |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Goods tariff number (HS) | 85176990 |
Other functions | |
number of antennas | 2 |
transmit power range | 20 - 20 dBmW |
