connections and interfaces | |
transmission technology | Kabellos |
host interface | USB |
interface | WLAN |
network | |
Maximum data transfer rate | 150 Mbit/s |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Eigenschaft | Schnellinstallationsanleitung |
WiFi band | Einzelband (2,4GHz) |
frequency range | 2,4 - 2,4835 GHz |
Top WLAN-Standard | Wi-Fi 4 (802.11n) |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Data transfer speed WiFi | 11,54,150 Mbit/s |
Modulation | 16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WMM, WPA-PSK, WPA2-PSK |
Design | |
Product color | Schwarz, Weiß |
The Antenna Design | Extern |
Antenna connector type | RP-SMA |
Antennenrichtungsart | Mit kugelförmiger Richtcharakteristik |
Antenna gain level (max) | 4 dBi |
Transmission power (CE) | 20 dbm |
Transmission power (FCC) | 27 dbm |
Betriebsmodi | Infrastrukturmodus |
system requirement | |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
sustainability | |
weight and dimensions | |
broad | 93,5 mm |
depth | 26 mm |
height | 11 mm |
package weight | 180 g |
scope of delivery | |
Supplied cables | USB |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
logistic data | |
Goods tariff number (HS) | 85176990 |
