Compliance certificates | Federal Communications Commission (FCC) |
Product colour | White |
Operating modes | Infrastructure mode |
Internal | No |
Antenna gain level (max) | 4 dBi |
Antenna Connector Type | RP-SMA |
Transmitting power (FCC) | 27 dBm |
Transmitting power (CE) | 20 dBm |
WPS push button | Yes |
Antenna | Yes |
Antenna direction type | Omni-directional |
Antenna design | External |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Height | 11 mm |
Depth | 26 mm |
Width | 93.5 mm |
Modulation | 64-QAM |
WLAN data transfer rates supported | 11 |
Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
Maximum data transfer rate | 150 Mbit/s |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Frequency range | 2.4 - 2.4835 GHz |
Networking standards | IEEE 802.11b |
Security algorithms | WPA-PSK |
Wi-Fi band | Single-band (2.4 GHz) |
Wi-Fi | Yes |
Windows operating systems supported | Windows 10 Education x64 |
Mac operating systems supported | Yes |
Linux operating systems supported | Yes |
PACKAGE WEIGHT | 180 g |
Package depth | 150 mm |
Package width | 200 mm |
Package height | 39 mm |
Quick installation guide | Yes |
Resource CD | Yes |
CABLES INCLUDED | USB |
Host Interface | USB |
Connectivity Technology | Wireless |
Interface | WLAN |
Harmonized System (HS) code | 85176990 |
Warnings | Do not disassemble or modify the device to avoid damage or electric shock. |
Sustainability compliance | Yes |
