Flash Memory | 256 MB |
INTERNAL MEMORY | 1000 MB |
Processor frequency | 2.6 MHz |
Processor cores | 4 |
Built-in processor | Yes |
Firmware upgradeable | Yes |
Product colour | Black |
On/off switch | Yes |
Indication light | Yes |
LED indicators | LAN, Power, WAN |
Product Type | Tabletop router |
AC input frequency | 50/60 Hz |
Output voltage | 12 V |
Output current | 5 A |
Power source type | DC |
AC input voltage | 110 - 240 V |
NAT functionality | PPTP Pass-Through
L2TP Pass-Through
IPSec Pass-Through
RTSP Pass-Through
H.323 Pass-Through
SIP Pass-Through
PPPoE Relay |
MAC Address Table | 64 entries |
Firewall | Yes |
Guest access | Yes |
Security algorithms | WPA2-Enterprise |
Filtering | Yes |
MAC address filtering | Yes |
DMZ support | Yes |
Parental control | Yes |
URL filtering | Yes |
Network address translation (NAT) | Yes |
Reset button | Yes |
Wake-on-LAN ready | Yes |
WPS push button | Yes |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
MU-MIMO technology | Yes |
Intelligent Mesh technology | Yes |
Bandwidth control | Yes |
Weight | 854 g |
Depth | 90 mm |
Width | 235 mm |
Height | 316 mm |
VPN support | Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark |
Ethernet LAN data rates | 2500 Mbit/s |
Dynamic DNS (DDNS) | Yes |
Networking standards | IEEE 802.11ax |
VPN server | VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard |
Support Samba (storage) | Yes |
Port triggering | Yes |
Port forwarding | Yes |
Ethernet LAN | Yes |
Ethernet LAN interface type | 10 Gigabit Ethernet |
Media server | Yes |
Package Type | Box |
Packaging content | RT-BE86U WiFi router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card |
Quick start guide | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Warranty card | Yes |
AC adapter included | Yes |
Wi-Fi standards | 802.11g |
WLAN data transfer rate (first band) | 1032 Mbit/s |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) | 5764 Mbit/s |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
WLAN data transfer rate (second band) | 5764 Mbit/s |
DHCP Server | Yes |
USB 2.0 ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 4 |
USB Port | Yes |
Antennas quantity | 4 |
Antenna design | Internal & external |
WAN connection type | RJ-45 |
3G/4G USB modem compatibility | No |
Ethernet WAN | Yes |
SIM card slot | No |
DSL WAN | No |
Warnings | The product may emit radio waves that may interfere with other electronic devices. |
