Product Type | Tabletop router |
LED indicators | Status |
Product colour | Black |
Power source type | AC |
External power adapter | Yes |
NAT functionality | Port Forwarding, Port Triggering, UPnP, DMZ |
Parental control | Yes |
Network address translation (NAT) | Yes |
Security algorithms | WPA-PSK |
Access Control List (ACL) | Yes |
Firewall security | SPI Firewall, IP/MAC Address Binding |
Firewall | Yes |
Guest access | Yes |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Web-based management | Yes |
Reset button | Yes |
WPS push button | Yes |
DESPITE | Yes |
MU-MIMO technology | Yes |
Width | 159.7 mm |
Depth | 125.9 mm |
Height | 37.1 mm |
Receiver sensitivity | 11g 6Mbps: -96dBm
11g 54Mbps: -78dBm
11n HT40 MCS7: -74dBm
11n HT20 MCS7: -71dBm
11a 6Mbps: -97dBm
11a 54Mbps: -79dBm
11ac VHT20 MCS8: -74dBm
11ac VHT40 MCS9: -70dBm
11ac VHT80 MCS9: -65dBm |
Cabling technology | 10/100/1000Base-T(X) |
Ethernet LAN | Yes |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN data rates | 10 |
Package Type | Box |
Antenna included | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Quick installation guide | Yes |
AC adapter included | Yes |
Wi-Fi standards | 802.11g |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) | 1167 Mbit/s |
WLAN data transfer rate (second band) | 867 Mbit/s |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (first band) | 300 Mbit/s |
DHCP Server | Yes |
Supported network protocols | PPPoE/L2TP/PPTP |
DHCP client | Yes |
DC-in jack | Yes |
USB Port | No |
Ethernet LAN (RJ-45) ports | 3 |
Antennas quantity | 4 |
Antenna type | External |
Antenna gain level (max) | 5 dBi |
Ethernet WAN | Yes |
WAN connection type | RJ-45 |
SIM card slot | No |
DSL WAN | No |
3G/4G USB modem compatibility | No |
