| Intel inside | Y |
| Product colour | Black |
| Product Type | Tabletop router |
| LED indicators | LAN, Power, Status, WAN |
| On/off switch | Yes |
| Output current | 2 A |
| Output voltage | 12 V |
| Power source type | AC |
| Firewall security | DoS, SPI |
| Firewall | Yes |
| DMZ support | Yes |
| Guest access | Yes |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| WPS push button | Yes |
| Width | 260.2 mm |
| Depth | 135 mm |
| Height | 41.6 mm |
| Receiver sensitivity | 2.4GHz: 11ac VHT20_MCS0:-96dBm 11ac VHT20_MCS8:-74dB 11ac VHT40_MCS0:-94dBm 11ac VHT40_MCS9:-70dB 11ax HE20_MCS0:-96dBm 11ax HE20_MCS11:-66dBm 11ax HE40_MCS0:-93dBm 11ax HE40_MCS11:-63dBm 5GHz: 11ac VHT20_MCS0:-97dBm 11ac VHT20_MCS8:-75dBm 11ac VHT40_MCS0:-94dBm 11ac VHT40_MCS9:-70dBm 11ac VHT80_MCS0:-91dBm 11ac VHT80_MCS9:-67dBm 11ac VHT160_MCS0:-88dBm 11ac VHT160_MCS9:-63dBm 11ax HE20_MCS0:-97dBm 11ax HE20_MCS11:-66dBm 11ax HE40_MCS0:-94dBm 11ax HE40_MCS11:-63dBm 11ax HE80_MCS0:-91dBm 11ax HE80_MCS11:-61dBm 11ax HE160_MCS0:-87dBm 11ax HE160_MCS11:-58dBm |
| Ethernet LAN data rates | 1000 Mbit/s |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN | Yes |
| Port forwarding | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Dynamic DNS (DDNS) | Yes |
| Windows operating systems supported | Windows 7 |
| Mac operating systems supported | Yes |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Linux operating systems supported | Yes |
| Mac compatibility | Yes |
| Number of products included | 1 pc(s) |
| Quick installation guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| CABLES INCLUDED | AC |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| DHCP Server | Yes |
| DHCP client | Yes |
| Supported network protocols | IPv4, IPv6 |
| Universal Plug and Play (UPnP) | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
| USB Port | No |
| Memory card slot(s) | No |
| Transmit power | CE: <20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz) FCC: <30dBm (2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz) |
| Antenna type | External |
| Antennas quantity | 4 |
| WAN connection type | RJ-45 |
| DSL WAN | No |
| SIM card slot | No |
| Ethernet WAN | Yes |
| 3G/4G USB modem compatibility | No |
| 3G | No |
| 4G | No |
| Mobile network generation | 4G |
