Product colour | Black |
LED indicators | LAN, Power, Status, WLAN, WPS |
On/off switch | Yes |
Product Type | Tabletop router |
Wall mountable | Yes |
Power source type | DC |
Output voltage | 12 V |
Stateful Packet Inspection (SPI) | Yes |
MAC address filtering | Yes |
Security algorithms | 128-bit WEP |
Access Control List (ACL) | Yes |
Firewall | Yes |
DMZ support | Yes |
Guest access | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Reset button | Yes |
WPS push button | Yes |
Ethernet LAN data rates | 10 |
Networking standards | IEEE 802.11a |
Ethernet LAN interface type | Gigabit Ethernet |
Cabling technology | 10/100/1000Base-T(X) |
Ethernet LAN | Yes |
Port forwarding | Yes |
Dynamic DNS (DDNS) | Yes |
Windows operating systems supported | Windows 8 Pro x64 |
Mac operating systems supported | MacOS |
Mac compatibility | Yes |
Linux operating systems supported | Yes |
Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
PACKAGE WEIGHT | 800 g |
Package width | 350 mm |
Package depth | 240 mm |
Package height | 82 mm |
AC adapter included | Yes |
CABLES INCLUDED | AC |
Quick installation guide | Yes |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max) | 1300 Mbit/s |
Wi-Fi standards | 802.11b |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (first band) | 1300 Mbit/s |
DHCP client | Yes |
DHCP Server | Yes |
Universal Plug and Play (UPnP) | Yes |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 5 |
USB Port | No |
Memory card slot(s) | No |
Antennas quantity | 4 |
Detachable antenna(s) | No |
Transmit power | CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz), FCC:<30dBm(2.4 GHz & 5 GHz) |
Antenna design | External |
Ethernet WAN | Yes |
SIM card slot | No |
WAN connection type | RJ-45 |
