Compliance certificates | Federal Communications Commission (FCC) |
Firmware upgradeable | Yes |
Product colour | White |
Product Type | Tabletop router |
On/off switch | Yes |
Output current | 1 A |
Power source type | AC |
Output voltage | 12 V |
IP address filtering | Yes |
Firewall | Yes |
MAC address filtering | Yes |
URL filtering | Yes |
DDoS protection | Yes |
Filtering | Yes |
Firewall security | NAT, SPI |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Web-based management | Yes |
WPS push button | Yes |
Depth | 138 mm |
Height | 44 mm |
Width | 204 mm |
Receiver sensitivity | 270M: -68dBm@10% PER,
130M: -68dBm@10% PER,
108M: -68dBm@10% PER,
54M: -68dBm@10% PER,
11M: -85dBm@8% PER,
6M: -88dBm@10% PER,
1M: -90dBm@8% PER |
Ethernet LAN data rates | 10 |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3u |
Ethernet LAN | Yes |
Ethernet LAN interface type | Fast Ethernet |
Windows operating systems supported | Windows 7 Home Basic |
Mac operating systems supported | Yes |
Linux operating systems supported | Yes |
Package width | 315 mm |
PACKAGE WEIGHT | 620 g |
Package depth | 240 mm |
Package height | 70 mm |
CABLES INCLUDED | LAN (RJ-45) |
Antenna included | Yes |
Quick installation guide | Yes |
AC adapter included | Yes |
Wi-Fi standards | 802.11b |
Modulation | 64-QAM |
Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
Wi-Fi band | Single-band (2.4 GHz) |
WLAN data transfer rate (max) | 300 Mbit/s |
USB Port | Yes |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 4 |
USB 2.0 ports quantity | 1 |
Antenna Connector Type | RP-SMA |
Antennas quantity | 2 |
Antenna design | External |
Antenna gain level (max) | 5 dBi |
Transmit power | 20 dBmW |
Antenna direction type | Omni-directional |
3G/4G USB modem compatibility | Yes |
Ethernet WAN | Yes |
WAN connection type | RJ-45 |
DSL WAN | No |
SIM card slot | No |
Harmonized System (HS) code | 85176990 |
Sustainability compliance | Yes |
Sustainability certificates | RoHS |
