features | |
Eigenschaft | Reset-Knopf |
Maximum data transfer rate | 1200 Mbit/s |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u |
safety | |
Supported security algorithms | AES, HTTPS, SSH, TKIP, WPA, WPA2 |
logs | |
management logs | SNMP |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
energy | |
output voltage | 12 V |
output current | 2 A |
Power consumption (max.) | 16,6 W |
Design | |
housing material | Kunststoff |
Antenna | |
Antenna gain level (max) | 6,5 dBi |
Technical details | |
shipping carton length | 56,5 cm |
shipping carton width | 34,3 cm |
shipping carton height | 27,5 cm |
Net weight of shipping carton | 6,39 kg |
Quantity per shipping carton | 6 Stück(e) |
Pallet length (gross) | 110 cm |
Pallet width (gross) | 120 cm |
Weight (inner) shipping carton | 7,3 kg |
certificates | |
certification | CEEN 301 893 V1.7.1 (2012-06) (DFS/TPC)EN 300 328 V1.8.1 (2012-06)FCCICcULLVDUL2043C-TickBSMINCC |
weight and dimensions | |
broad | 158,8 mm |
depth | 158,8 mm |
height | 69,4 mm |
Weight | 500 g |
package weight | 1,06 kg |
operating conditions | |
Operating relative humidity | 10 - 90% |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 65 °C |
logistic data | |
Goods tariff number (HS) | 85176990 |
