2.4 GHz | Yes |
Receiver sensitivity 2.4 GHz | 802.11n 20 MHz: -73 dBm at MCS7 |
Receiver sensitivity 5 GHz | 802.11a: -92 dBm at 6Mbps, -74 dBm at 54Mbps |
Maximum data transfer rate (2.4 GHz) | 573.5 Mbit/s |
Maximum data transfer rate | 1170 Mbit/s |
OFDMA | Y |
Networking standards | IEEE 802.11ax |
MU-MiMO | Yes 2x2:2 |
Maximum Tx power (2.4 GHz) | 24 dBm |
Number of users | 256 user(s) |
Shooting distance | 175 m |
Maximum transmission power (5 GHz) | 22 dBm |
5 GHz | Yes |
Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
Product colour | White |
Cable lock slot | Yes |
Reset button | Yes |
Mounting Kit | Yes |
Mounting style | Ceiling, wall |
LED indicators | Yes |
Suitable for outdoor use | No |
Security algorithms | WPA2-Enterprise |
MAC address filtering | Yes |
Safe start-up | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Management software | Yes |
WebGui | Yes |
Cloud-managed | Yes |
Width | 180.4 mm |
Height | 180.4 mm |
Depth | 40.8 mm |
Weight | 443 g |
Supported network protocols | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
Ethernet LAN (RJ-45) ports | 2 |
Network interface | Base-T 10/100/1000 with auto detection |
Captive portal | Yes |
MU-MIMO technology | Yes |
Gamepad | Y |
QoS SUPPORT | TOS |
VLAN support | Yes |
Number of SSID supported | 32 |
Fast roaming | Yes |
Quality of Service (QoS) support | Yes |
PoE standard | IEEE 802.3af/at |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 9 W |
