WAN connection | |
Eigenschaft | LED-Anzeigen |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3 |
Ethernet interfaces type | Gigabit Ethernet |
wiring technology | 10/100/1000Base-T(X) |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Transferrate | 1 Mpps |
number of users | 200 Benutzer |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
Anzahl WAN-Ports | 1 |
Anzahl der Konsolen-Ports | 1 |
Number of USB ports | 1 |
USB-Version | 2.0 |
logs | |
Router protocol | BGP, BGP4+, IS-IS, OSPF, OSPFv3, RIP, RIPng |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
safety | |
Supported security algorithms | IPSec, SNMP |
authentication method | MAC address authentication, Portal authentication |
VPN support | IPsec VPN, GRE VPN, DSVPN, L2TP VPN, L2TPv3VPN |
certificates | |
Konformitätsbescheinigungen | Elektromagnetische Verträglichkeit (EMV), REACH, RoHS, WEEE |
features | |
storage media | Flash |
Internal storage capacity | 1 GB |
Flash memory | 1000 MB |
Design | |
Product color | Weiß |
energy | |
Power consumption (standard operation) | 9 W |
Power consumption (max.) | 12 W |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
input current | 0.8 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
operating height | 0 - 5000 m |
weight and dimensions | |
broad | 240 mm |
depth | 161,5 mm |
height | 38 mm |
Weight | 580 g |
package weight | 1,18 kg |
