| Receiver sensitivity | 5 GHz: -80 dBm @ 54 MBit/s, IEEE 802.11an/ac: -75 dBm @ (MCS7, 20/40MHz), -71 dBm @ (MCS9, 20/40 MHz), -68 dBm (MCS9, 80 MHz)
2.4 GHz: -80 dBm @ 54 MBit/s, IEEE 802.11n: -77 dBm @ (MCS7, 20 MHz), -75 dBm @ (MCS7, 40 MHz) |
| Maximal-Ratio Combining (MRC) | Yes |
| Maximum indoor range | 30 m |
| Dynamic Frequency Selection (DFS) | Yes |
| Quality of Service (QoS) support | Yes |
| VLAN support | Yes |
| Operating modes | Access Point (AP),Bridge,Client |
| Maximum Likelihood Detection (MLD) | Yes |
| Networking standards | IEEE 802.11h |
| Automatic channel selection | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Fast roaming | Yes |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Rate limiting | Yes |
| Throughput data rate | 250 Mbit/s |
| 6 GHz | No |
| Maximum outdoor range | 150 m |
| Ethernet LAN data rates | 100 |
| 5 GHz | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| DESPITE | Yes |
| Frequency Band | 2.4 - 2.4835, 5.15 - 5.7 GHz |
| 2.4 GHz | Yes |
| Reset button | Yes |
| LED indicators | Yes |
| Placement | Wall |
| Housing material | Metal |
| Internal | No |
| International Protection (IP) code | IP50 |
| Product colour | Grey |
| Power consumption (max) | 12.95 W |
| Power Over Ethernet (PoE) | Yes |
| Security Features | Terminal Access Controller Access-Control System Plus (TACACS+), Password authentication protocol (PAP) |
| Access Control List (ACL) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Security algorithms | AES |
| Auto Wireless Distribution System (WDS) | Yes |
| Wireless Intrusion Detection System (WIDS) | Yes |
| IGMP snooping | Yes |
| Operating temperature (T-T) | -20 - 50 °C |
| Syslog | Yes |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Width | 210 mm |
| Height | 33 mm |
| Depth | 152 mm |
| Package height | 94 mm |
| Package depth | 288 mm |
| PACKAGE WEIGHT | 2.35 kg |
| Package width | 385 mm |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Mounting Kit | Yes |
| Quantity per pack | 1 pc(s) |
| CABLES INCLUDED | LAN (RJ-45) |
| Supported protocols | IPv4:
DNS, HTTP, HTTPS, ICMP, NTP/SNTP, NetBIOS, PPPoE (server), RADIUS, RADSEC, RTP, SNMP, SNMPv3, TFTP, TACACS+
IPv6:
NDP, SLAAC, DHCPv6, ICMPv6, DHCPv6, DNS, HTTP, HTTPS, PPPoE, RADIUS, SMTP, NTP, BGP |
| DHCP Server | Yes |
| Routing protocols | RIP-1 |
| Management protocols | SSL, SSH, HTTPS, SNMP, Telnet, TFTP, SNMP, HTTP |
| DHCP client | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Number of connectors | 4 |
| Antenna Connector Type | SMA |
| Antenna type | External |
| Harmonized System (HS) code | 85176990 |
| Customs product code (TARIC) | 85176200 |
| Country of origin | Germany |
