Housing material | Steel |
Product colour | Black |
Rack mounting | No |
LED indicators | Yes |
Number of power supply units | 1 |
Power supply included | Yes |
Power source | DC/PoE |
AC input frequency | 50 Hz |
Input voltage | 53.5 V |
Power consumption (max) | 144.1 W |
Input current | 2.43 A |
AC input voltage | 90 - 220 V |
IGMP snooping | Yes |
Heat dissipation | 482.17 BTU/h |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Width | 209 mm |
Height | 26 mm |
Depth | 126 mm |
10G support | No |
Cable types supported | Cat3 |
Flow control support | Yes |
Auto-negotiation | Yes |
MAC address auto-learning supported | Yes |
MAC address auto-aging supported | Yes |
Networking standards | IEEE 802.3at |
Copper ethernet cabling technology | 100BASE-TX |
Auto MDI/MDI-X | Yes |
Fanless | Yes |
Package Type | Box |
User guide | Yes |
CABLES INCLUDED | AC |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 10 |
Gigabit Ethernet (copper) ports quantity | 10 |
Combo SFP ports quantity | 1 |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 4000 entries |
Forwarding rate | 14.88 Mpps |
Store-and-forward | Yes |
Switching capacity | 20 Gbit/s |
Power over Ethernet plus (PoE+) ports quantity | 2 |
Power over Ethernet 4PPoE (PoE++) ports quantity | 6 |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 123 W |
