Receiver sensitivity | 802.11a:54M: -75dBm, 48M: -76dBm, 36M: -83dBm, 6-24M: -95dBm802.11n:MCS15: -73dBm, MCS14: -74dBm, MCS13: -76dBm,MCS12: -80dBm, MCS11: -83dBm, MCS10: -88dBm,MCS9: -90dBm, MCS8: -93dBm, MCS7: -73dBm,MCS6: -74dBm, MCS5: -76dBm, MCS4: -80dBm,MCS3: -83dBm, MCS2: -88dBm, MCS1: -90dBm, MCS0: -93dBm |
Networking standards | IEEE 802.11a |
Throughput data rate | 300 Mbit/s |
Frequency Band | 5.15 - 5.85 GHz |
Automatic channel scanning | Yes |
Cabling technology | 10/100Base-T(X) |
Bandwidth | 5 GHz |
Ethernet LAN data rates | 100 |
2.4 GHz | No |
Automatic channel selection | Yes |
Maximum outdoor range | 15000 m |
Maximum data transfer rate | 300 Mbit/s |
5 GHz | Yes |
Certification | - FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- RoHS |
Product colour | White |
Housing material | Plastic |
International Protection (IP) code | IP5X |
LED indicators | Yes |
Reset button | Yes |
Placement | Pole |
Power Over Ethernet (PoE) | Yes |
Input voltage | 100 - 240 V |
Input current | 0.8 A |
Input Frequency | 50/60 Hz |
Power consumption (typical) | 13 W |
Security algorithms | WPA |
MAC address filtering | Yes |
IP address filtering | Yes |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -30 - 70 °C |
Web-based management | Yes |
Management platform | Pharos Control |
Width | 224.4 mm |
Height | 60.3 mm |
Depth | 79 mm |
Compatible operating systems | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
Processor frequency | 560 MHz |
INTERNAL MEMORY | 64 MB |
Built-in processor | Yes |
Flash Memory | 8 MB |
Processor architecture | MIPS 74Kc |
Processor model | Qualcomm Atheros |
Package depth | 132 mm |
PACKAGE WEIGHT | 720 g |
Package height | 106 mm |
Package width | 270 mm |
CABLES INCLUDED | AC |
Management protocols | TDMA |
WAN connection | Ethernet (RJ-45) |
Ethernet LAN (RJ-45) ports | 1 |
Antenna direction type | Omni-directional |
Antennas quantity | 1 |
Antenna features | Integrated antenna |
Antenna gain level (max) | 13 dBi |
Antenna type | Internal |
