features | |
Eigenschaft | Schnellstartübersicht |
Maximum data transfer rate | 1775 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
Ethernet LAN data transfer rates | 100,1000 Mbit/s |
frequency band | 2.4 - 5 GHz |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
MIMO-Type | Multi User MIMO |
Spread-Spectrum Methode | OFDMA |
Transmission power (CE) | <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz band1/2, EIRP); <25 dBm (5 GHz band3) |
Transmission power (FCC) | <25 dBm (2.4 GHz); <25 dBm (5 GHz) |
safety | |
Supported security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3 |
Anzahl der SSID-Unterstützung | 16 |
management functions | |
management platform | Omada |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
energy | |
Power over Ethernet (PoE) type supported | Passive PoE |
DC voltage range | 12 V |
input current | 1 A |
Power consumption (standard operation) | 9,6 W |
Power consumption (max.) | 10,6 W |
Design | |
placement | Zimmerdecke, Wand |
Product color | Weiß |
Antenna | |
antenna type | Intern |
number of antennas | 4 |
Antenna gain level (max) | 5 dBi |
Services | |
Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
certificates | |
certification | CE, FCC, RoHS |
weight and dimensions | |
broad | 160 mm |
depth | 160 mm |
height | 33,6 mm |
scope of delivery | |
quantity per pack | 1 Stück(e) |
operating conditions | |
Operating relative humidity | 0 - 40% |
operating temperatur | 10 - 90 °C |
Storage temperature range | -40 - 70 °C |
humidity during storage | 5 - 90% |
