features | |
Eigenschaft | Montageset |
Maximum data transfer rate | 2402 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
Maximum data transfer rate (5 GHz) | 2402 Mbit/s |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
frequency band | 2.4, 5 GHz |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
wiring technology | 10/100/1000Base-T(X) |
number of users | 100 Benutzer |
Transmission power (CE) | 20 - 23 - 26 dbm |
Transmission power (FCC) | 21 - 21 dbm |
safety | |
Supported security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise |
Features Service Set Identifier (SSID) | Multiple SSIDs |
Anzahl der SSID-Unterstützung | 16 |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
WAN port | Ethernet (RJ-45) |
energy | |
Power consumption (standard operation) | 12 W |
Design | |
placement | Wand |
Product color | Weiß |
Antenna | |
antenna type | Intern |
number of antennas | 2 |
Antenna gain level (max) | 5 dBi |
Services | |
Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
certificates | |
Konformitätsbescheinigungen | RoHS |
certification | FCC, RoHS |
weight and dimensions | |
broad | 143 mm |
depth | 86 mm |
height | 42,6 mm |
package weight | 400 g |
packaging type | Box |
scope of delivery | |
quantity per pack | 1 Stück(e) |
operating conditions | |
Operating relative humidity | 10 - 90% |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
humidity during storage | 5 - 90% |
