Design | |
Product color | Weiß |
LED indicators | Leistung |
antenna type | Intern |
number of antennas | 4 |
Anzahl der unterstützten Geräte | 150 |
transmit power | CE: ≤20 dBm (2.4GHz), ≤23 dBm (5GHz) |
Eigenschaft | Ethernet-Kabel |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
WLAN data transfer rate (first band) | 574 Mbit/s |
WLAN data transfer rate (second band) | 1201 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Supported security algorithms | WPA, WPA-PSK, WPA3 |
Number of guest networks (5 GHz) | 1 |
Number of guest networks (2.4 GHz) | 1 |
mobile network | |
Cellular Network Generation | 3G, 4G |
3G standards | DC-HSPA+, HSPA, UMTS |
4G-Standards | TD-LTE & FDD-LTE |
Supported UMTS bandwidths | 850,900,2100 MHz |
supported 4G bandwidths | 700,800,850,900,1800,2100,2300,2500,2600 MHz |
SIM card type | NanoSIM |
features | |
number of CPU cores | 4 |
processor clock speed | 1,5 GHz |
Cloud-Services unterstützt | TP-Link ID |
Supporting WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Betriebsmodi | 3G/4G, Router, Access Point |
logs | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 3 |
energy | |
AC input voltage | 100 - 240 V |
AC-Adapter Eingangsstrom | 0,6 A |
AC input frequency | 50/60 Hz |
power supply output voltage | 12 V |
AC adapter output current | 1,5 A |
certificates | |
certification | CE, RoHS |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 60 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 105 mm |
depth | 105 mm |
height | 167 mm |
scope of delivery | |
Number of products included | 1 Stück(e) |
Anzahl der enthaltenen Einheiten | 1 Stück(e) |
package weight | 1,22 kg |
logistic data | |
Goods tariff number (HS) | 85171800 |
