features | |
Eigenschaft | Montageset |
Maximum data transfer rate | 100 Mbit/s |
Wi-Fi data rate (max) | 300 Mbit/s |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
frequency band | 2.4 - 2.4835 GHz |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
number of users | 64 Benutzer |
number of channels | 13 Kanäle |
Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, QPSK |
Betriebsmodi | Access Point (AP),Gateway,Repeater,WISP |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
Features Service Set Identifier (SSID) | SSID-Übertragung ein/aus |
Anzahl der SSID-Unterstützung | 4 |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
WAN port | Ethernet (RJ-45) |
energy | |
AC input voltage | 12 V |
input current | 1 A |
Design | |
placement | Stange |
Product color | Weiß |
International degree of protection (IP code) | IP65 |
Antenna | |
number of antennas | 2 |
Antenna gain level (max) | 5 dBi |
certificates | |
certification | CE |
weight and dimensions | |
broad | 87 mm |
depth | 257 mm |
height | 38 mm |
Weight | 400 g |
package weight | 700 g |
packaging type | Box |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
operating conditions | |
Operating relative humidity | 10 - 90% |
operating temperatur | -40 - 55 °C |
Storage temperature range | -40 - 70 °C |
humidity during storage | 5 - 90% |
logistic data | |
Goods tariff number (HS) | 85176990 |
Country of origin | China |
Shipping box width | 350 mm |
Shipping carton length | 495 mm |
Shipping carton height | 452 mm |
Shipping carton weight | 2,1 kg |
Number of products per shipping carton | 20 Stück(e) |
