features | |
Eigenschaft | Schnellstartübersicht |
Maximum data transfer rate | 433 Mbit/s |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
frequency band | 2.4 - 5.825 GHz |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x |
number of users | 80 Benutzer |
number of channels | 36 Kanäle |
Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP |
Features Service Set Identifier (SSID) | SSID-Übertragung ein/aus |
Anzahl der SSID-Unterstützung | 8 |
management functions | |
Switch-Typ | Managed |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
WAN port | Ethernet (RJ-45), WLAN |
energy | |
output voltage | 12 V |
output current | 1,5 A |
Power consumption (standard operation) | 15 W |
Design | |
placement | Zimmerdecke, Wand |
Product color | Weiß |
LED indicators | Leistung, WLAN |
Antenna | |
Antennenrichtungsart | Mit kugelförmiger Richtcharakteristik |
antenna functions | Integrierte Antenne |
number of antennas | 3 |
Antenna gain level (max) | 15 dBi |
certificates | |
certification | CE/FCC |
weight and dimensions | |
broad | 189 mm |
depth | 38,5 mm |
height | 189 mm |
Weight | 326 g |
package weight | 680 g |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
operating conditions | |
Operating relative humidity | -20 - 50% |
operating temperatur | -40 - 70 °C |
Storage temperature range | 5 - 90 °C |
humidity during storage | 10 - 90% |
logistic data | |
Goods tariff number (HS) | 85176990 |
