Warranty period | 2 year(s) |
Certification | IEC 62196, IEC 62752, IEC 60309, EN 300 220-1/2, EN 300 328, EN 301 489-1/17, EN 301 489-1/3,
EN 301 489-1/52, EN 301 511 |
Firmware upgradeable | Yes |
Power source type | AC |
Wi-Fi | Yes |
Vehicle charging standard | Mode 3 |
Direct current failure monitoring | Yes |
International Protection (IP) code | IP54 |
Over current protection | Yes |
Vehicle connection plug | Type 2 |
Mechanical impact protection code | IK10 |
LED indicators | Error |
Cable colour | Black |
Built-in Display | Yes |
Display Technology | LED |
Mounting Type | Wall |
Housing material | Aluminium |
Integrated energy meter | Yes |
Housing colour | Grey |
Integrated charging cable | Yes |
Number of phases | 3 |
Maximum operating current (three-phase) | 32 A |
Maximum operating power (single-phase) | 7.2 kW |
Maximum operating power (three-phase) | 22 kW |
Maximum charging power | 22000 W |
Maximum operating current per phase | 32 A |
Minimum operating power (single-phase) | 1.4 kW |
Three-phase output voltage supported | 400 V |
Single-phase output voltage supported | 230 V |
Weight | 5.51 kg |
Height | 338 mm |
Charging cable length | 5 m |
Depth | 73 mm |
Width | 211 mm |
