Sustainability certificates | CE |
Sustainability compliance | Yes |
Cross-section connection | 5 x 10 mm² |
IEC protection class | III |
Mechanical impact protection code | IK08 |
International Protection (IP) code | IP54 |
Socket type | Type 2 |
Sockets quantity | 1 |
Power source type | AC |
Quantity per pack | 1 pc(s) |
Wi-Fi | Yes |
Vehicle connection plug | Type 2 |
Built-in Display | No |
Cable colour | Black |
LED indicators | Yes |
Housing colour | Black |
Mounting Type | Wall |
Single-phase output voltage supported | 220 |
Maximum charging power | 7400 W |
Number of phases | 3 |
Voltage tolerance | 10% |
Maximum operating current (three-phase) | 32 A |
Maximum operating power (three-phase) | 7.4 kW |
Three-phase output voltage supported | 400 V |
Nominal frequency | 60 Hz |
Operating temperature (T-T) | -25 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Depth | 82 mm |
Width | 163 mm |
Weight | 1 kg |
Height | 166 mm |
Charging cable length | 7 m |
