Sustainability certificates | Green Premium |
Audible alarm(s) | Yes |
Surge protection features | Network |
Output operation voltage (max) | 230 V |
UPS topology | Line-Interactive |
Output Power Capacity | 2.2 kVA |
Maximum current | 12 A |
Automatic Voltage Regulation (AVR) | Yes |
Waveform | Sine |
EMI/RFI noise filtering | Yes |
Input Frequency | 50/60 Hz |
Surge energy rating | 1080 J |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Input operation voltage (min) | 168 V |
Input operation voltage (max) | 302 V |
Surge protection | Yes |
Output frequency | 60 Hz |
Response time | 8 ms |
Output Power | 1320 W |
Noise level | 45 dB |
Certification | IEC 62040-1-1
IEC 62040-2 |
Display type | LCD |
International Protection (IP) code | IP20 |
Cable length | 1.52 m |
Product colour | Black |
Rack capacity | 0U |
Form factor | Tower |
Non-operating altitude | 0 - 3048 m |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 40 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3048 m |
Storage relative humidity (H-H) | 0 - 95% |
Height | 292.1 mm |
Width | 104.1 mm |
Depth | 408.9 mm |
PACKAGE WEIGHT | 14.5 kg |
Weight | 12.3 kg |
Package depth | 480 mm |
Package width | 355 mm |
Package height | 155 mm |
CABLES INCLUDED | USB cable |
Manual | Yes |
AC outlet types | C13 coupler |
Cabling technology | 10/100/1000Base-T(X) |
Power plug | Type F |
Serial interface type | RJ-45 |
USB Port | Yes |
AC outlets quantity | 6 AC outlet(s) |
Battery Technology | Sealed Lead Acid (VRLA) |
Cold start | Yes |
Automatic battery test | Yes |
Battery life (max) | 5 year(s) |
Battery Recharge Time | 16 h |
Battery voltage | 24 V |
Number of batteries supported | 1 |
