Total carbon footprint (kg of CO2e) | 3327.3 |
Compliance certificates | RoHS |
Sustainability certificates | Green Premium |
Web-based management | Yes |
Audible alarm(s) | Yes |
Response time | 4 ms |
Noise level | 55 dB |
Output Power | 1980 W |
Input Frequency | 50/60 Hz |
Surge protection | Yes |
Output Power Capacity | 2.2 kVA |
Input operation voltage (min) | 151 V |
Input operation voltage (max) | 302 V |
UPS topology | Line-Interactive |
Waveform | Sine |
Surge energy rating | 375 J |
Audible alarm modes | Battery replacement |
Output operation voltage (max) | 240 V |
Output frequency | 50/60 Hz |
Output operation voltage (min) | 220 V |
Auto-restart | Yes |
Emergency Power Off (EPO) | O |
Certification | CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE |
Rack capacity | 2U |
Product colour | Black |
LED indicators | Yes |
Form factor | Rackmount |
Display type | LCD |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Package height | 254 mm |
Weight | 42.2 kg |
Depth | 683 mm |
Width | 480 mm |
Height | 86 mm |
Package width | 600 mm |
CABLES INCLUDED | Input power cable, USB cable |
Quick installation guide | Yes |
Resource CD | Yes |
Rack mount kit | Yes |
Ethernet LAN (RJ-45) ports | 1 |
AC outlets quantity | 9 AC outlet(s) |
USB 2.0 ports quantity | 1 |
Power plug | C20 coupler |
AC outlet types | C20 coupler |
Battery Technology | Sealed Lead Acid (VRLA) |
Battery capacity | 509 Ah |
Automatic battery test | Yes |
Battery Recharge Time | 5 h |
Cold start | Yes |
Hot-swap battery | Yes |
Output voltage | 230 V |
Harmonized System (HS) code | 85078000 |
